Emporia Vue 3
Circuit energy monitor
$149.99
$199.99
$99.99
Sold out
Free standard shipping to the 48 contiguous states, usually in 3 to 7 business days. Price confirmed before payment.
Understand circuit energy use with the Vue 3. Choose the exact eight- or sixteen-sensor kit for your measurement plan.
- 8 CT · Branch sensors
- 2 CT · Main sensors
- 2.4 GHz · Wi-Fi band
- 16 CT · Branch sensors
- 2 CT · Main sensors
- 2.4 GHz · Wi-Fi band
- 0 CT · Branch sensors
- 2.4 GHz · Wi-Fi band
- ±2 % · Published measurement accuracy
Prefer USDT? Request an invoice
Exact US configurationProduct details reviewed
What this equipment is for
For understanding where electricity goes before planning upgrades or backup. The selected kit includes two main sensors plus either eight or sixteen branch sensors.
What to check before buying
Requires installation in an electrical panel, compatible service and an internet connection. Interval energy data does not verify a compressor’s instantaneous starting demand.
Monitor detail. Sensors are included according to the selected kit.
Make your energy use visible.
For understanding where electricity goes before planning upgrades or backup. The selected kit includes two main sensors plus either eight or sixteen branch sensors.
Explore shopping helpSpecifications
8 branch sensors + 2 main sensorsSKU EMV3A-2P-8
Energy measurement
- Branch sensors
- 8 CT
- Main sensors
- 2 CT
- Rating per included main sensor
- 200 A
- Rating per branch sensor
- 50 A
- Published measurement accuracy
- ±2 %
- Maximum sensing voltage per channel (L–N)
- 264 V AC
- Sensor cable length
- 1 m
- Monitor power consumption
- <3 W
Connections & expansion
- Wi-Fi band
- 2.4 GHz
- Ethernet
- 10/100Base-T · IEEE 802.3
- Internet for app and cloud data
- Required
Dimensions & operating conditions
- Monitor dimensions (H × W × D)
- 145 × 70 × 28 mm
- Monitor operating temperature
- −40–50 °C
- Installation environment
- Indoor, dry location
Warranty & certifications
- Manufacturer warranty
- 1 year
- Safety certifications
- UL 61010 / UL 2808
16 branch sensors + 2 main sensorsSKU EMV3A-2P-16
Energy measurement
- Branch sensors
- 16 CT
- Main sensors
- 2 CT
- Rating per included main sensor
- 200 A
- Rating per branch sensor
- 50 A
- Published measurement accuracy
- ±2 %
- Maximum sensing voltage per channel (L–N)
- 264 V AC
- Sensor cable length
- 1 m
- Monitor power consumption
- <3 W
Connections & expansion
- Wi-Fi band
- 2.4 GHz
- Ethernet
- 10/100Base-T · IEEE 802.3
- Internet for app and cloud data
- Required
Dimensions & operating conditions
- Monitor dimensions (H × W × D)
- 145 × 70 × 28 mm
- Monitor operating temperature
- −40–50 °C
- Installation environment
- Indoor, dry location
Warranty & certifications
- Manufacturer warranty
- 1 year
- Safety certifications
- UL 61010 / UL 2808
Monitor Only — no branch sensorsSKU EMV3A-2P-WH
Energy measurement
- Branch sensors
- 0 CT
- Published measurement accuracy
- ±2 %
- Maximum sensing voltage per channel (L–N)
- 264 V AC
- Sensor cable length
- 1 m
- Monitor power consumption
- <3 W
Connections & expansion
- Wi-Fi band
- 2.4 GHz
- Ethernet
- 10/100Base-T · IEEE 802.3
- Internet for app and cloud data
- Required
Dimensions & operating conditions
- Monitor dimensions (H × W × D)
- 145 × 70 × 28 mm
- Monitor operating temperature
- −40–50 °C
- Installation environment
- Indoor, dry location
Warranty & certifications
- Manufacturer warranty
- 1 year
- Safety certifications
- UL 61010 / UL 2808
Manufacturer specifications for the selected configuration.
What arrives in the box.
- Vue 3 monitor, Wi-Fi antenna and cable, wiring harness
- Two 200 A main current sensors
- 8 branch current sensors (50 A)
- Vue 3 monitor, Wi-Fi antenna and cable, wiring harness
- Two 200 A main current sensors
- 16 branch current sensors (50 A)
- Vue 3 monitor; consult the manufacturer’s exact Monitor Only configuration for included wiring and sensors.
Compare equipment.
Open full comparison
| Equipment | Vue 38 branch sensors + 2 main sensorsView product | Vue 316 branch sensors + 2 main sensorsView product |
|---|---|---|
| Price | ||
| Branch sensors | 8 CT | 16 CT |
| Main sensors | 2 CT | 2 CT |
| Manufacturer warranty | 1 year | 1 year |
| Wi-Fi band | 2.4 GHz | 2.4 GHz |
| Rating per included main sensor | 200 A | 200 A |
| Rating per branch sensor | 50 A | 50 A |
| Published measurement accuracy | ±2 % | ±2 % |
Open full comparison
| Equipment | Vue 316 branch sensors + 2 main sensorsView product | Vue 38 branch sensors + 2 main sensorsView product |
|---|---|---|
| Price | ||
| Branch sensors | 16 CT | 8 CT |
| Main sensors | 2 CT | 2 CT |
| Manufacturer warranty | 1 year | 1 year |
| Wi-Fi band | 2.4 GHz | 2.4 GHz |
| Rating per included main sensor | 200 A | 200 A |
| Rating per branch sensor | 50 A | 50 A |
| Published measurement accuracy | ±2 % | ±2 % |
Open full comparison
| Equipment | Vue 3Monitor Only — no branch sensorsView product | Vue 38 branch sensors + 2 main sensorsView product |
|---|---|---|
| Price | ||
| Branch sensors | 0 CT | 8 CT |
| Main sensors | — | 2 CT |
| Manufacturer warranty | 1 year | 1 year |
| Wi-Fi band | 2.4 GHz | 2.4 GHz |
| Published measurement accuracy | ±2 % | ±2 % |
| Maximum sensing voltage per channel (L–N) | 264 V AC | 264 V AC |
| Ethernet | 10/100Base-T · IEEE 802.3 | 10/100Base-T · IEEE 802.3 |
Your questions.
Who is this equipment for?
For understanding where electricity goes before planning upgrades or backup. The selected kit includes two main sensors plus either eight or sixteen branch sensors.
What should I verify before choosing?
Requires installation in an electrical panel, compatible service and an internet connection. Interval energy data does not verify a compressor’s instantaneous starting demand.
What warranty applies?
Emporia lists a one-year warranty. Coverage for the exact product and BetterPowered sales program will be confirmed before purchase.
What about delivery and returns?
Free standard shipping to eligible U.S. addresses. Request a return within 30 days of delivery for unused, uninstalled equipment in its original packaging. For change-of-mind returns, you pay return shipping; BetterPowered adds no restocking fee. Contact us for return authorization. Installation is separate.
Which payment methods do you accept?
Pay securely by credit or debit card. Affirm and Klarna offer payment plans for eligible personal equipment purchases. Checkout shows the methods available for your order.
Can I finance my purchase?
Yes. Choose Affirm or Klarna at checkout for eligible personal equipment purchases. Review your payments and terms before accepting. For contractor-managed installation projects, ask about BetterPowered Capital. Financing is subject to eligibility and approval.
Can I place an order?
Yes. Add the equipment to your cart and complete secure checkout on the website or in the app. Review your delivery address, taxes, total and return terms before paying.
